HC038V/BT
Control body | Bluetooth with 0/1-10V | Attachable sensor heads
BENEFITS
- Adaptable: Small control unit with strain relief
- Versatile: Choose over many sensors options
- Control through bluetooth your 0/1-10V luminaires
APPLICATIONS
- Master luminaire with sensor
- Classrooms
- Offices
Product information "HC038V/BT"
HC038V/BT is a Bluetooth-enabled 0/1-10V control base with a built-in 30mA power supply, compatible with a wide range of microwave and PIR (Passive Infrared) sensor heads. It is more suitable for plastic luminaires, ensuring stable connectivity and performance in plastic lighting applications.
| Ambient temperature max.: | 55 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Bluetooth Platform: | Nordic nRF52832 |
| Bluetooth frequency: | 2.4 GHz |
| Bluetooth range: | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Commissioning Methods: | App & Web (Bluetooth) |
| Connector Type: | Standard 2 cables |
| Daylight Harvest: | Yes |
| Detection Methods: | Microwave (MW), Passive Infrared (PIR) |
| Detection angle: | 360° |
| Dimming (Output) Interface: | 0/1-10V |
| Human Centric Lightning (HCL): | Yes |
| IP Rate: | IP20 |
| Installation Type: | Built-in |
| Load capacitive: | 400.0000 VA |
| Load resistive: | 800.0000 W |
| Max withstandable in-rush current: | 80A@160μs |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product height: | 21.0000 mm |
| Product length: | 120.0000 mm |
| Product weight: | 60.4000 g |
| Product width: | 30.0000 mm |
| Tri-level (Corridor function): | Yes |
| Voltage Type: | AC |
| Warming-up: | 20 s |
| Zhaga: | No |
Datasheets
Product datasheet: hc038v-bt.pdf
Installation Manual
User manual: installation-manual-hc038v-bt.pdf
