HIR09/AA
PIR Highbay | Adjustable Angle | RJ12 connector to control body
BENEFITS
- Compact: Standard rectangular Plug&Play sensor design
- Simple: Daylight harvest with Photocell
- User-Friendly: With one-key commissioning with IR controller
APPLICATIONS
- Corridors / Walkways application
- Industry
- Offices
Product information "HIR09/AA"
This PIR sensor features adjustable angle design and includes daylight harvesting, a photocell for light sensing, and active lux switching capabilities. Sensor settings are adjustable via the HRC-11 handset, and it is IP65 rated for protection of the lens/facia part.
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | IR Remote Controller |
| Connector Type: | RJ12 |
| Daylight Sensor Option: | Ordinary Photodiode/Photocell |
| Detection Methods: | Passive Infrared (PIR) |
| Detection angle: | 360° |
| Detection range (DxH): | 24x15 |
| Features: | Adjustable Angle, Daylight Harvest |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Plug & Play Sensor Heads |
| Lens type: | High-bay |
| Maximum Mounting Height: | 15.0000 m |
| Mounting Height: | High-bay |
| Mounting hole: | 80.0000 mm |
| Operating Voltage: | 5 VDC |
| Product height: | 90.0000 mm |
| Product weight: | 117.0000 g |
| Product width: | 75.0000 mm |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Tri-level (Corridor function): | No |
| Voltage Type: | DC |
