HIR19/AA
PIR Highbay | Adjustable Angle | RJ12 connector to control body
Vorteile
- Compact: Standard rectangular Plug&Play sensor design
- Simple: Tri-level dimming control with Photocell
- User-Friendly: With one-key commissioning with IR controller
ANWENDUNGEN
- Corridors / Walkways application
- Corridor/Hallway
- Classrooms,/Offices
Produktinformationen "HIR19/AA"
Featuring an adjustable angle design, this PIR sensor offers tri-level dimming, photocell functionality, and active lux switching. It enables convenient settings adjustment via handset HRC-11 and boasts IP65 protection for reliable performance in diverse conditions.
| Anschlusstyp: | RJ12 |
|---|---|
| Betriebsspannung: | 5 VDC |
| Detection angle: | 360° |
| Detektionsverfahren: | Passive Infrared (PIR) |
| Erfassungsbereich (DxH): | 24x15 |
| Features: | Adjustable Angle, Tri-level (Corridor Function) |
| Human Centric Lightning (HCL): | Nein |
| Inbetriebnahmemethoden: | Remote Controller |
| Installationstyp: | Plug & Play Sensor Heads |
| Montagehöhe: | High-bay |
| Schutzart: | IP20 |
| Tageslicht Sensor Option: | Ordinary Photodiode/Photocell |
| Tri-level (Korridorfunktion): | Ja |
| Voltage Type: | DC |
| Warming-up: | 20 s |
| Zhaga: | No |
