HED1025
LED Driver 25W Dimmable| DALI & SwitchDim | Built-in version
Vorteile
- Compact: Linear LED Hex-Driver with plugable RJ12 Sensorhead
- Flexible: Switch-Dim input for manual control
- Easy: Configurable constant current (CC) output via DIP switches
ANWENDUNGEN
- Linear Luminaire Built-in integration
- Offices
- Classrooms
Produktinformationen "HED1025"
HED1025 is a detached DALI LED Driver with Switch-Dim, the maximum ouput is 25W. By simply connecting Bluetooth sensor head HBT01/HBT02/HIR13/HIR16/HIR62/HIR62/R to the driver, it allows for motion detection and Bluetooth mesh control. Once the sensor head is connected to the driver, DALI control are then disabled and sensor antenna will take control. With Bluetooth wireless mesh networking, it makes communication between luminaires much easier without time-consuming hardwiring, which eventually saves costs for projects.Meanwhile, simple device setup and commissioning can be done via Koolmesh app.
| Ausgangsleistung: | 28W |
|---|---|
| Ausgangsspannung: | 12~60V |
| Befestigungsloch: | 4.2000 mm |
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Bluetooth Frequenz: | 2.4 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Dimmschnittstelle: | DALI |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| Human Centric Lightning (HCL): | Nein |
| Installationstyp: | Built-in |
| Lagertemperatur: | 70 °C |
| Lagertemperatur min.: | -40 °C |
| Operating Mode: | Constant Current |
| Product height: | 21.5000 mm |
| Produktlänge: | 269.0000 mm |
| Produkttiefe: | 36.0000 mm |
| Schutzart: | IP20 |
| Taster Eingänge: | |
| Treiber Typ: | Dimming Only |
| Tri-level (Korridorfunktion): | Nein |
| Umgebungstemperatur: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Wirkungsgrad: | 88 % |
