HIR02/FM

PIR Lowbay | Tri-level dimming | RJ12 connector to control body

BENEFITS

Compact: Standard rectangular Plug&Play sensor design
Simple: Tri-level dimming with photocell
User-Friendly: With one-key commissioning with IR controller

APPLICATIONS

Flush mount application
Classrooms
Offices

Product information "HIR02/FM"

This PIR sensor features flush mount installation and passive infrared (PIR) detection. It supports tri-level dimming, includes a photocell for daylight sensing, and offers active lux switching capabilities. Suitable for installations up to 3m high with a detection range up to Ø = 18m, sensor settings can be adjusted via the HRC-05 handset.

Ambient temperature max.:	50 °C
Ambient temperature min.:	-20 °C
Commissioning Methods:	Remote Controller
Connector Type:	RJ12
Daylight Harvest:	Yes
Daylight Sensor Option:	Ordinary Photodiode/Photocell
Detection Methods:	Passive Infrared (PIR)
Detection angle:	360°
Detection range (DxH):	18×3
Features:	Tri-level (Corridor Function)
Human Centric Lightning (HCL):	No
Humidity max:	90 %
Humidity min:	10 %
IP Rate:	IP20
Installation Type:	Plug & Play Sensor Heads
Lens type:	Standard Low-bay
Mounting Height:	Low-bay
Mounting hole spacing:	41.0000 mm
Operating Voltage:	5 VDC
Product height:	30.4000 mm
Product width:	48.0000 mm
Storage temperature max.:	70 °C
Storage temperature min.:	-40 °C
Tri-level (Corridor function):	Yes
Voltage Type:	DC
Zhaga:	No
