HC438
Control body | ON/OFF | Attachable sensor heads
BENEFITS
- Adaptable: Small control unit with strain relief
- Versatile: Suitable for various sensor head options via Plug’n’Play
- Easy setting: Configuration with IR controller
APPLICATIONS
- Master luminaire with sensor
- School/Classrooms
- Office/Commercial Lighting
Product information "HC438"
HC438 is am occupancy detector with on/off control suitable for indoor use.
| Ambient temperature max.: | 55 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | IR Remote Controller |
| Connector Type: | RJ12 |
| Detection Methods: | Microwave (MW), Passive Infrared (PIR) |
| Dimming (Output) Interface: | Relay On/Off |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Built-in |
| Mounting hole: | 4.5000 mm |
| Operating voltage range: | 120-277 VAC |
| Product height: | 21.0000 mm |
| Product length: | 120.0000 mm |
| Product weight: | 60.0000 g |
| Product width: | 30.0000 mm |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Tri-level (Corridor function): | No |
| Voltage Type: | AC |
| Warming-up: | 20 s |
| Zhaga: | No |
Datasheets
Product datasheet: hc438.pdf
Login
Compatible products (for full functionality)
Bluetooth Network Components
