HBTD8200P/F
Bluetooth Receiver | 4 SELV Push | Screw Mounting
BENEFITS
- Compact: Two screw holes to be built inside luminaires
- Functional: On/Off+ Dimming control + Colour tuning + Scene recall via app
- Flexible: 4 SELV Push switch for manual control
APPLICATIONS
- Built-in luminaries
- Bluetooth receiver node
- Offices, Classrooms, Industry and Healthcare Spaces
Product information "HBTD8200P/F"
The HBTD8200P/F features 4 SELV push inputs, enabling Bluetooth control for on/off, dimming, color tuning, and scene recall. Designed to fit into junction boxes or electrical boxes, it enhances standard lighting fixtures with intelligent control for both new builds and retrofit projects. Setup and commissioning are effortless via the Koolmesh app.
| Application Type: | Controller for Built-in Luminaire |
|---|---|
| Bluetooth frequency: | 2.4 GHz - 2.483 GHz |
| Bluetooth range (Phone to Device) : | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Commissioning Methods: | App & Web (Bluetooth) |
| IP Rate: | IP20 |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Output Voltage: | 220~240VAC 50/60Hz |
| Product height: | 18.0000 mm |
| Product length: | 58.0000 mm |
| Product weight: | 39.0000 g |
| Product width: | 46.0000 mm |
| Push Button Input: | 4 |
| Zhaga: | No |
Datasheets
Product datasheet: hbtd8200p-f.pdf
