HBP02
Bluetooth Touch Panel | Real-time keeper | 4 scenes
Vorteile
- Minimalist: Very clear actions for each button
- Configurable: Up to 4 scenes and colour dimming
- Auto: Tell the sensor to take over and keep real time
ANWENDUNGEN
- Wall switch mounting boxes
- Classrooms, Meeting rooms
- Maintenance and control rooms
Produktinformationen "HBP02"
HBP02 is a wall-mounted touch panel meticulously crafted to seamlessly interface with the Hytronik range of Bluetooth products. It offers 6 programmable scenes, along with precise control over brightness and tunable white settings. Elevating user experience, we've introduced a "sensor take-over" button and a "clean mode" button for added functionality.
Programming the HBP02 is effortlessly achieved through the Koolmesh app, providing users with a versatile and user-friendly platform for customization. Experience enhanced control and convenience with HBP02, ensuring optimal operation and versatility in managing your lighting preferences.
Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
---|---|
Bluetooth Frequenz: | 2.4 GHz |
Bluetooth Reichweite: | 10-30m |
Bluetooth Sendeleistung: | 4 dBm |
Bluetooth System: | Koolmesh |
Bluetooth Technologie: | Nordic nRF52832 |
Category - System Level Components: | Wall Panel |
Feuchtigkeit max: | 90 % |
Feuchtigkeit min: | 20 % |
Product height: | 36.0000 mm |
Produktlänge: | 98.0000 mm |
Produkttiefe: | 86.0000 mm |
Schutzart: | IP20 |
Umgebungstemperatur: | 50 °C |
Umgebungstemperatur min.: | 20 °C |
Zhaga: | No |
