HBTD8200T/F
Bluetooth Receiver | Trailing Edge | Screw Mounting
Vorteile
- Compact: Two screw holes to be built inside luminaires
- Professional: Trailing edge output with 150VA (capacitive)
- Flexible: 2 Push inputs for manual control
ANWENDUNGEN
- Built-in luminaries
- Bluetooth receiver node
- Offices, Classrooms, Industry and Healthcare Spaces
Produktinformationen "HBTD8200T/F"
This device is designed to fit into a junction box or electrical box, enabling push switch (retractive switch) control for on/off, dimming, color tuning, and scene recall functionalities. It offers trailing-edge output: 150VA (capacitive), making it suitable for both new build and retrofit projects to add intelligent control to standard lighting fixtures. Setup and commissioning are straightforward via the Koolmesh app.
| Application Type: | Controller for Built-in Luminaire |
|---|---|
| Ausgangsschnittstelle: | Trailing edge (Phasenabschnittsteuerung) |
| Ausgangsspannung: | 230VAC 50Hz |
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Product height: | 22.0000 mm |
| Produktlänge: | 58.0000 mm |
| Produkttiefe: | 46.0000 mm |
| Schutzart: | IP20 |
| Taster Eingänge: | 2 |
| Zhaga: | No |
