HBTD8200V/F
Bluetooth Receiver | 0/1-10V | Screw Mounting
Vorteile
- Compact: Two screw holes to be built inside luminaires
- Simple: 0/1-10V dimming control
- Flexible: 2 Push inputs for manual control
ANWENDUNGEN
- Built-in luminaires
- Offices, Classrooms
- Industry and Healthcare Spaces
Produktinformationen "HBTD8200V/F"
HBTD8200VF is designed as Bluetooth built-in
receiver node. It can be used alongside our Bluetooth
motion sensor range as Bluetooth receiver nodes. Or, it can
also be used solely as Bluetooth control unit for each luminaire.
Whether for home use, commercial or industrial applications,
HBTD8200VF do it all. Simple device setup and
commissioning can be done via Koolmesh app.
Application Type: | Controller for Built-in Luminaire |
---|---|
Ausgangsschnittstelle: | 0/1-10V |
Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
Bluetooth Reichweite: | 10-30m |
Bluetooth Sendeleistung: | 4 dBm |
Bluetooth System: | Koolmesh |
Bluetooth Technologie: | Nordic nRF52832 |
Feuchtigkeit max: | 90 % |
Feuchtigkeit min: | 20 % |
Human Centric Lightning (HCL): | Nein |
Inbetriebnahmemethoden: | App & Web (Bluetooth) |
Lagertemperatur: | 70 °C |
Lagertemperatur min.: | -40 °C |
Product height: | 22.0000 mm |
Produktlänge: | 58.0000 mm |
Produkttiefe: | 46.0000 mm |
Schutzart: | IP20 |
Taster Eingänge: | 2 |
Tri-level (Korridorfunktion): | Nein |
Umgebungstemperatur: | -45 °C |
Umgebungstemperatur min.: | -20 °C |
Zhaga: | No |
