HTG02/F
Real-time Keeper | Bluetooth Repeater Module | Screw Fixation
BENEFITS
- Tiny: Installation holes for switch mounting boxes
- Reinforced: Optional external antennas to improve signal
- Convinient: Accurate timekeeping for up to 12 weeks during power loss
APPLICATIONS
- Warehouses, manufacturing plants
- Large areas with "signal dead spots"
- Sites with general on/off cycles
Product information "HTG02/F"
HTG02/F is Bluetooth modules with a real-time chip built in that can keep real time running for up to 12 weeks during power loss, which is very convenient for Bluetooth system/network where there is constant need for power on/off. When a product group mesh network is created, the entire network takes HTG02/F as the authoritative time. External Bluetooth antenna can be connected for a longer Bluetooth broadcast distance.
| Ambient temperature max.: | 60 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Bluetooth frequency: | 2.4 GHz |
| Bluetooth range: | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Category - System Level Components: | Real-time Keeper/Repeater Module |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Mounting hole: | 3.1000 mm |
| Operating Voltage: | 120-277 VAC |
| Product height: | 22.0000 mm |
| Product length: | 58.0000 mm |
| Product weight: | 40.0000 g |
| Product width: | 46.0000 mm |
| Push Button Input: | |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
