Coming Soon / In Development
HBIR29/WM
Bluetooth DALI PIR Lowbay wide range | minor movement detection | Integrated 60 mA PSU
BENEFITS
- Discreet: Recessed design integrates neatly into the ceiling
- Sensitive: PIR and micro-motion sensing improves presence detection
- Flexible: Allowing push switch & app setup
APPLICATIONS
- Offices
- Meeting Rooms
- Quiet Public Spaces (Libraries, Galleries)
Product information "HBIR29/WM"
HBIR29/WM is a Bluetooth PIR presence sensor designed for offices and other low-movement indoor spaces, featuring high-sensitivity PIR and micro-motion detection to maintain reliable presence sensing even when occupants remain relatively still. Integrated daylight sensing supports occupancy- and daylight-based lighting control, while the built-in 60mA DALI power supply simplifies DALI system installation. Bluetooth Mesh enables wireless lighting control without additional control wiring, and compatible D4i drivers provide energy, fault and diagnostic data for system monitoring. All configuration and commissioning can be completed easily via the Koolmesh App.
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Bluetooth Platform: | Nordic nRF52832 |
| Bluetooth frequency: | 2.4 GHz - 2.483 GHz |
| Bluetooth range (Phone to Device) : | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Commissioning Methods: | App & Web (Bluetooth) |
| Daylight Harvest: | Yes |
| Daylight Sensor Option: | Photocell Advance |
| Detection Methods: | Passive Infrared (PIR) |
| Detection angle: | 360° |
| Detection range (Diameter): | 20×5 |
| Dimming (Output) Interface: | DALI/DALI-2 |
| Features: | Daylight Harvest, Tri-level (Corridor Function), Tunable White Control / HCL |
| Human Centric Lightning (HCL): | Yes |
| Humidity max: | 90 % |
| Humidity min: | 20 % |
| IP Rate: | IP54 |
| Installation Type: | Stand-alone |
| Maximum Mounting Height: | 5.0000 m |
| Mounting Height: | Low-bay |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product Status: | Coming Soon / In Development |
| Product height: | 66.3000 mm |
| Product length: | 102.0000 mm |
| Product width: | 102.0000 mm |
| Push Button Input: | 2 |
| Storage temperature max.: | 50 °C |
| Storage temperature min.: | -20 °C |
| Tri-level (Corridor function): | Yes |
| Voltage Type: | AC |
| Warming-up: | 20 s |
| Zhaga: | No |
Datasheets
Product datasheet: hbir29-wm.pdf
