HBEM03
Emergency Driver 45W | Bluetooth remote control dimmable| LiFePO4
Vorteile
- Compact: Emergency Driver with Bluetooth
- Flexible: Choose over many sensors options via plug & play
- Cost-Saving: BLE eliminates the need for time-consuming hardwiring and onsite check
ANWENDUNGEN
- Luminaire Built-in integration or standalone
- Retrofit upgrades & New luminaire designs
- Offices, Classrooms, Industry and Healthcare Spaces
Produktinformationen "HBEM03"
HBEM03 is a combined LED driver & emergency control gear with Bluetooth module built inside. HBEM03 is ideal for lighting manufacturers with new plastic luminaire design. It can conduct monthly or annually testing automatically and user can get email notification as soon as fault is detected. Meanwhile, simple device setup and commissioning can be done via Koolmesh app.
| Ausgangsspannung: | 60V |
|---|---|
| Befestigungsloch: | 4.1000 mm |
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Bluetooth Frequenz: | 2.4 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Bluetooth Technologie: | Nordic nRF52832 |
| Category - Emergency LED Drivers & Inverters: | LED Driver & Inverter Combo (Bluetooth) |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| Human Centric Lightning (HCL): | Ja |
| Lagertemperatur: | 45 °C |
| Lagertemperatur min.: | -10 °C |
| Product height: | 23.0000 mm |
| Produktlänge: | 140.7000 mm |
| Produkttiefe: | 79.2000 mm |
| Schutzart: | IP20 |
| Taster Eingänge: | 1 |
| Tri-level (Korridorfunktion): | Ja |
| Umgebungstemperatur: | 50 °C |
| Umgebungstemperatur min.: | 0 °C |
