Coming Soon / In Development
HBTD54S/N
Bluetooth Dimmer | 4 Wires 1 Circuits | ON/OFF Control
BENEFITS
- Compact: Enabling plug-in Bluetooth On/Off control
- Stable: Ensuring safe operation with zero-cross protection
- Flexible: Allowing wireless setup and parameter adjustment via app
APPLICATIONS
- Compatible with Global, Powergear, and equivalent standard track systems
- Offices, Retail stores, Warehouse
- Museums, Galleries
Product information "HBTD54S/N"
HBTD54S/N is a Bluetooth on/off dimmer for track lighting systems, enabling wireless switching control and upgrading conventional track luminaires to smart lighting. It features a built-in zero-crossing protection circuit to reduce inrush current, ensuring system stability and reliability. With simple plug-in track installation and no extra wiring, all parameters can be quickly and wirelessly configured through the Koolmesh app.
| Ambient temperature max.: | 45 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Application Type: | Controller for Track Lighting |
| Bluetooth Platform: | Nordic nRF52832 |
| Bluetooth frequency: | 2.4 GHz - 2.483 GHz |
| Bluetooth range (Phone to Device) : | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Commissioning Methods: | App & Web (Bluetooth) |
| Dimming (Output) Interface: | Relay On/Off |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Load capacitive: | 400.0000 VA |
| Load resistive: | 800.0000 W |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product Status: | Coming Soon / In Development |
| Product height: | 115.5000 mm |
| Product length: | 110.7000 mm |
| Product width: | 31.0000 mm |
| Storage temperature max.: | 60 °C |
| Storage temperature min.: | -20 °C |
| Tri-level (Corridor function): | No |
| Zhaga: | No |
Datasheets
Product datasheet: hbtd54s-n.pdf
