HEM09H
Emergency Driver Max.30w | Constant Current | Attachable sensor heads
Vorteile
- Compact: Emergency driver with self-test optional remote
- 3 in 1: LED Driver + Emergency control + Sensor heads
- Flexible: Multiple current selection/Emergency power via DIP-Swiches
ANWENDUNGEN
- Luminaire Built-in Emergency integration
- Utility / Back of house (Bulkhead)
- Offices, Classrooms
Produktinformationen "HEM09H"
Emergency conversion units to provide constant power output in emergencymode. 1-10V and Switch-Dim, or controlled by SAM7 and SAM7/FM.
| Ausgangsspannung: | 33V |
|---|---|
| Befestigungsloch: | 4.1000 mm |
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Category - Emergency LED Drivers & Inverters: | LED Driver & Inverter Combo (Non-Bluetoooth) |
| Daylight Harvest: | Nein |
| Detektionsverfahren: | Microwave (MW) |
| Erfassungsbereich (DxH): | 12x6 |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| HF Betriebsfrequenz (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | Nein |
| Montagehöhe: | Low-bay |
| Product height: | 23.0000 mm |
| Produktlänge: | 140.6000 mm |
| Produkttiefe: | 79.2000 mm |
| Schutzart: | IP20 |
| Taster Eingänge: | 1 |
| Tri-level (Korridorfunktion): | Nein |
| Umgebungstemperatur: | 50 °C |
| Umgebungstemperatur min.: | 0 °C |
| Wirkungsgrad: | 85 % |
