HBTD8200VFC/F
Bluetooth Switch | Voltage-free Contact | Screw Mounting
BENEFITS
- Compact: Two screw holes to be built inside luminaires
- Flexible: Freely select NO or NC contact
- Flexible: 1 Push inputs for manual control
APPLICATIONS
- Built-in luminaires
- Offices, Classrooms
- Industry and Healthcare Spaces
Product information "HBTD8200VFC/F"
HBTD8200VFC/F is designed to fit into a junction box or
electrical box to make Push switch (retractive switch) to achieve
on/off control. It can choose from a variety of
free voltage loads. It has NO and NC Relay suitable for various
alarm systems or BMS signal access. Whether used for new build
or retrofit projects to add intelligent control to standard lighting fixtures, HBTD8200VFC/F does it all. Simple device setup and commissioning can be done via Koolmesh app.
| Ambient temperature max.: | 45 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Application Type: | Controller for Built-in Luminaire |
| Bluetooth frequency: | 2.4 GHz - 2.483 GHz |
| Bluetooth range: | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Dimming (Output) Interface: | Volt-free Contact (VFC) |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Operating Voltage: | 220-240 VAC 50/60 Hz |
| Product height: | 22.0000 mm |
| Product length: | 58.0000 mm |
| Product width: | 46.0000 mm |
| Push Button Input: | 2 |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Zhaga: | No |
