HBTD8200VFC
Bluetooth Switch | Voltage-free Contact | Wall Junction Box
BENEFITS
- Compact: Designed to fit into Wall Junction Box
- Flexible: Freely select NO or NC contact
- Flexible: 1 Push inputs for manual control
APPLICATIONS
- Bluetooth receiver node
- Offices, Classrooms
- Industry and Healthcare Spaces
Product information "HBTD8200VFC"
HBTD8200VFC is designed to fit into a junction box or electrical
box to make Push switch (retractive switch) to achieve on/off
control. It can choose from a variety of free voltage
loads. It has NO and NC Relay suitable for various alarm systems
or BMS signal access. Whether used for new build or retrofit
projects to add intelligent control to standard lighting fixtures. HBTD8200VFC does it all. Simple device setup and commissioning can be done via Koolmesh app.
| Ambient temperature max.: | 45 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Application Type: | Dimmers for Wall Junction Box |
| Bluetooth Platform: | Nordic nRF52832 |
| Bluetooth frequency: | 2.4 GHz - 2.483 GHz |
| Bluetooth range (Phone to Device) : | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Commissioning Methods: | App & Web (Bluetooth) |
| Dimming (Output) Interface: | Volt-free Contact (VFC) |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product height: | 22.0000 mm |
| Product length: | 46.0000 mm |
| Product weight: | 39.0000 g |
| Product width: | 46.0000 mm |
| Push Button Input: | 2 |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Zhaga: | No |
Datasheets
Product datasheet: hbtd8200vfc.pdf
