HBTD54
Bluetooth Dimmer | 6 Wires 3 Circuits | Track system stucci
BENEFITS
- Integrated: Bluetooth module built-in + DALI broadcast output
- Standardized: 3-phase dial for phase selection
- Easy configuration: Wireless Bluetooth 5.0 SIG-Mesh
APPLICATIONS
- Designed to fit into stucci track system
- Offices, Retail stores, Warehouse
- Museums, Galleries
Product information "HBTD54"
HBTD54 is a Bluetooth dimming controller for the DALI track system, with
3-phase dial, DALI broadcast output and PSU integrated. The installation only
requires simple insertion into the track, to achieve on/off control, dimming
control, colour tuning and even scene recall. HBTD54 is suitable for the track
light which used for new builds or retrofit projects to add intelligent control to
standard lighting fixtures. Moreover, HBTD54 is practical and good-looking
since needless wiring. All simple device setup and commissioning can be done via Koolmesh app.
| Ambient temperature max.: | 40 °C |
|---|---|
| Ambient temperature min.: | -10 °C |
| Application Type: | Controller for Track Lighting |
| Bluetooth Platform: | Nordic nRF52832 |
| Bluetooth frequency: | 2.4 GHz - 2.483 GHz |
| Bluetooth range (Phone to Device) : | 10-30m |
| Bluetooth system: | Koolmesh |
| Bluetooth transmit power: | 4 dBm |
| Commissioning Methods: | App & Web (Bluetooth) |
| DALI Bus Current Consumption: | 80.0000 mA |
| Dimming (Output) Interface: | DALI/DALI-2 |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product height: | 45.9000 mm |
| Product length: | 261.6000 mm |
| Product weight: | 120.0000 g |
| Product width: | 31.0000 mm |
| Push Button Input: | 0 |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Zhaga: | No |
Datasheets
Product datasheet: hbtd54.pdf
