HBEM06
Emergency Sign Maintained Max.4w | Bluetooth control | Attachable sensor heads
FEATURES
- Compact: Max. 4W Main Power EM Power Supply
- All-in-one: Emergency functions with Bluetooth with optional sensor
- Cost-Saving: BLE eliminates the need for time-consuming hardwiring
ANWENDUNGEN
- Built-in Emergency Exit Sign light
- Retrofit upgrades & New luminaire designs
- Offices, Classrooms, Industry and Healthcare Spaces
Produktinformationen "HBEM06"
HBEM06 is a low-power, dimmable multifunctional emergency power module specifically designed for exit sign luminaires. Both mains and emergency outputs can be set to 1W, 2W, or 4W via DIP switch.With an RJ11 interface, it supports external sensor head connection.An SL terminal is provided for mains lighting compatibility (by connecting SL to L).Powered by a 6.4V LiFePO4 battery for safe and reliable emergency operation.Meanwhile, simple device setup and commissioning can be done via Koolmesh app.
| Betriebsspannung: | 220-240 VAC 50/60 Hz |
|---|---|
| Bluetooth-Plattform: | Nordic nRF52832 |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Human Centric Lightning (HCL): | Nein |
| IP-Schutzart: | IP20 |
| Kategorie - Notlicht LED-Treiber und & Inverter: | LED Treiber & Inverter Kombination (Bluetooth) |
| Korridorfunktion: | Nein |
| Lagertemperatur: | 70 °C |
| Min. Lagertemperatur: | -40 °C |
| Produktbreite: | 39.7000 mm |
| Produkthöhe: | 21.3000 mm |
| Produktlänge: | 139.0000 mm |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | 0 °C |
Datenblätter
Produktdatenblatt: hbem06.pdf
