HED8040/BT ECO
Bluetooth LED Driver 40W (CC) | Tunable white | Built-in
CARACTERÍSTICAS
- Compact: Constant current LED Driver with Bluetooth interface
- Innovative: Featuring Switch-Dim and Bluetooth dimming interfaces
- Easy configuration: via Dip-switch & Wireless Bluetooth 5.0 SIG-Mesh
APLICACIONES
- Retrofit projects with no extra wiring for control
- Offices
- Classrooms
Información sobre el producto "HED8040/BT ECO"
HED8040/BT is a Bluetooth dimming and color tuning LED driver with 40W max power output. It has a Switch-Dim interface via a Push switch. It is ideal for direct projects or new luminaire designs for lighting manufacturers. With Bluetooth wireless mesh networking, it makes communication between luminaires much easier without time-consuming hardwiring, which eventually saves costs for projects.
| Alcance del Bluetooth: | 10-30m |
|---|---|
| Altura del producto: | 27.0000 mm |
| Anchura del producto: | 32.0000 mm |
| Distancia entre orificios de montaje: | 4.2000 mm |
| Eficiencia: | 88 % |
| Frecuencia Bluetooth: | 2.4 GHz - 2.483 GHz |
| Human Centric Lightning (HCL): | Sí |
| Longitud del producto: | 330.0000 mm |
| Modo de funcionamiento: | Corriente constante |
| Potencia de salida: | 26 - 44W |
| Potencia de transmisión de Bluetooth: | 4 dBm |
| Protección IP: | IP20 |
| Sistema Bluetooth: | Koolmesh |
| Tecnología Bluetooth: | Nordic nRF52832 |
| Temperatura ambiente máx.: | 50 °C |
| Temperatura ambiente mín.: | -20 °C |
| Tipo de driver: | Regulación y ajuste de color |
| Tipo de montaje: | Para integrar |
| Tri-nivel (Función pasillo): | No |
| Voltaje de operación: | 220-240 VAC 50/60 Hz |
