HIM54
PIR + HF Highbay | Daylight Harvest | Remote Controller
BENEFITS
- Compact: Standard rectangular stand alone sensor design
- Simple: Daylight harvest Control for lndependent DALI
- User-Friendly: With one-key commissioning with Remote Control
APPLICATIONS
- Standalone installation for ceiling up to 12m
- Warehouse/ Logistic
- Production/ Industry
Product information "HIM54"
HIM54 is a standalone dual sense motion sensor featuring both HF and PIR technologies. It offers daylight harvesting control for independent DALI systems, ensuring efficient lighting management. Ideal for high bay installations, it enhances energy savings and lighting accuracy.
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | IR Remote Controller |
| Connector Type: | Standard 2 cables |
| DALI Bus Current Consumption: | 40.0000 mA |
| Daylight Harvest: | Yes |
| Daylight Sensor Option: | Photodiode/Photocell |
| Detection Methods: | Dual-Sense (MW+PIR) |
| Detection angle: | 360° |
| Detection range (Diameter): | 16×12 |
| Dimming (Output) Interface: | DALI |
| Features: | Daylight Harvest |
| HF operating frequency (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Stand-alone |
| Lens type: | Standard Low-bay |
| Maximum Mounting Height: | 12.0000 m |
| Mounting Height: | Mid & High-bay |
| Mounting hole: | 38.6000 mm |
| Operating voltage range: | 120-277 VAC |
| Product height: | 50.2000 mm |
| Product length: | 109.0000 mm |
| Product weight: | 190.0000 g |
| Product width: | 109.0000 mm |
| Push Button Input: | 2 |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Tri-level (Corridor function): | No |
| Voltage Type: | AC |
| Warming-up: | 30 s |
| Zhaga: | No |
Datasheets
Product datasheet: him54.pdf
Installation Manual
User manual: installation-manual-him54.pdf
