SAM7/AA
HF Lowbay | Tri-level & Adjustable Angle | RJ12 connector to control body
Vorteile
- Compact: Standard rectangular Plug&Play sensor design
- Innovative: Robus HF antenna design against wireless interface
- User-Friendly: With one-key commissioning with IR controller
ANWENDUNGEN
- Adjustable angle detection
- Corridor, Hallway
- Classrooms, Offices
Produktinformationen "SAM7/AA"
SAM7/AA is a HF sensor head and compatible with the Tri-level Dimming. It can work with the linear shaped control base such as HCD038/P and HCD038. It offers powerful number of Plug’n’Play feature options to expand the flexibility of luminaires design.
Anschlusstyp: | RJ12 |
---|---|
Befestigungsloch: | 90.0000 mm |
Betriebsspannung: | 5 VDC |
Daylight Harvest: | Nein |
Detection angle: | 360° |
Detektionsverfahren: | Microwave (MW) |
Erfassungsbereich (DxH): | 12x6 |
Features: | Adjustable Angle, Tri-level (Corridor Function) |
Feuchtigkeit max: | 990 % |
Feuchtigkeit min: | 10 % |
HF Betriebsfrequenz (Ghz): | 5.8Ghz+/-75MHz |
Human Centric Lightning (HCL): | Nein |
Inbetriebnahmemethoden: | Remote Controller |
Installationstyp: | Plug & Play Sensor Heads |
Lagertemperatur: | 70 °C |
Lagertemperatur min.: | -40 °C |
Maximale Montagehöhe: | 6.0000 m |
Montagehöhe: | Low-bay |
Product height: | 75.0000 mm |
Produktlänge: | 90.0000 mm |
Produkttiefe: | 90.0000 mm |
Schutzart: | IP20 |
Tageslicht Sensor Option: | Ordinary Photodiode/Photocell |
Tri-level (Korridorfunktion): | Ja |
Umgebungstemperatur: | 55 °C |
Umgebungstemperatur min.: | -20 °C |
Voltage Type: | DC |
Warming-up: | 20 s |
Zhaga: | No |
