SAM5/FM
HF Lowdbay | Tri-level dimming | RJ12 connector to control body
BENEFITS
- Compact: Standard rectangular Plug&Play sensor design
- Simple: Tri-level dimming control based upon occupancy
- User-Friendly: With one-key commissioning with IR controller
APPLICATIONS
- Flush mount installation
- Classrooms
- Offices
Product information "SAM5/FM"
This sensor features microwave (HF) detection and is designed for flush mount installation. It includes tri-level dimming, a photodiode (PD), active lux switching capabilities, with a maximum installation height of 6m and a detection range up to Ø = 12m. Sensor settings can be adjusted using the HRC-05 handset.
| Commissioning Methods: | IR Remote Controller |
|---|---|
| Connector Type: | RJ12 |
| Detection Methods: | Microwave (MW) |
| Features: | Tri-level (Corridor Function) |
| Human Centric Lightning (HCL): | No |
| IP Rate: | IP20 |
| Installation Type: | Plug & Play Sensor Heads |
| Mounting Height: | Low-bay |
| Mounting hole: | 39.0000 mm |
| Operating voltage range: | 5 VDC |
| Product height: | 26.5000 mm |
| Product length: | 48.0000 mm |
| Product weight: | 35.0000 g |
| Product width: | 48.0000 mm |
| Tri-level (Corridor function): | Yes |
| Voltage Type: | DC |
| Warming-up: | 20 s |
