HMW28/PRO
True Occupancy | ON/OFF | Surface mounting
BENEFITS
- High accuracy: True Occupancy technology for sensitive detection
- Simple: Daylight, detection range / holdtime
- Robust: configuration via remote controller
APPLICATIONS
- Standalone installation for ceiling up to 3m
- Office/ Meeting rooms
- Schools
Product information "HMW28/PRO"
HMW28/PRO is Microwave standalone motion sensor integrated with Hytronik True occupancy detection technology, On/Off control with one relay channel output, which is NO (normally open contact). The Hytronik True occupancy detection technology works to detect human breathing rather than the mirror movements. No matter if the person sit/stand statically or turns their back to the sensor. The sensor can accurately recognize occupancy and keeps the lights on all the time. It is ideal for typical indoor applications such asclassroom, office, healthcare, and other commercial areas.
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | IR Remote Controller |
| Connector Type: | Standard 2 cables |
| Daylight Harvest: | No |
| Detection Methods: | Microwave (MW), Microwave True Occupancy |
| Detection range (Diameter): | 10x3 |
| Dimming (Output) Interface: | Relay On/Off |
| Features: | Daylight Harvest |
| HF operating frequency (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Stand-alone |
| Maximum Mounting Height: | 3.0000 m |
| Mounting Height: | Low-bay |
| Mounting hole: | 66.0000 mm |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Output Voltage: | 220~240VAC 50/60Hz |
| Product height: | 73.0000 mm |
| Product length: | 85.0000 mm |
| Product weight: | 129.0000 g |
| Product width: | 78.0000 mm |
| Tri-level (Corridor function): | No |
| Voltage Type: | AC |
| Zhaga: | No |
Datasheets
Product datasheet: hmw28-pro.pdf
Installation Manual
User manual: installation-manual-hmw28-pro.pdf
