HMW24
HF Lowbay | Daylight Harvest & DALI | Ceiling mounting
BENEFITS
- Adaptable: Protection cover for high-voltage terminals
- 2 in 1: DALI output + Daylight Harvest
- Selectable: Rotatory swith for most common values/via IR controller
APPLICATIONS
- Remote ceiling or surface mounting (with accessory)
- Car parks
- Offices, Industry
Product information "HMW24"
HMW24 is a stand-alone HF motion sensor equipped with daylight harvesting, tailored for integration with independent DALI systems. This functionality allows precise control over lighting levels based on natural light conditions, optimizing energy efficiency in various indoor environments.
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | IR Remote Controller |
| Connector Type: | Standard 2 cables |
| DALI Bus Current Consumption: | 40.0000 mA |
| Daylight Harvest: | Yes |
| Detection Methods: | Microwave (MW) |
| Detection angle: | 360° |
| Detection range (Diameter): | 12x6 |
| Dimming (Output) Interface: | DALI |
| Features: | Daylight Harvest |
| HF operating frequency (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Stand-alone |
| Maximum Mounting Height: | 6.0000 m |
| Mounting Height: | Low-bay |
| Mounting hole: | 64.7000 mm |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product height: | 73.3000 mm |
| Product length: | 85.0000 mm |
| Product weight: | 96.0000 g |
| Product width: | 85.0000 mm |
| Push Button Input: | 2 |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Tri-level (Corridor function): | No |
| Voltage Type: | AC |
| Warming-up: | 20 s |
| Zhaga: | No |
Datasheets
Product datasheet: hmw24.pdf
Installation Manual
User manual: installation-manual-hmw24.pdf
