HED5040
DT6 LED Driver 40W (CC) Dimmable | 6 Wires 3 Circuits | Track System Stucci
BENEFITS
- Standardized: 3-phase dial for phase selection
- Professional: With DALI-2 dimming interface
- Easy: Configurable constant current (CC) output via DIP switches
APPLICATIONS
- Designed to fit into stucci track system
- Offices, Retail stores, Warehouse
- Museums, Galleries
Product information "HED5040"
HED5040 is a DALI-2 dimmable LED driver for the track system, with 3-phase dial and maximum power output of 40W. The installation only requires simple insertion into the track. HED5040 has a DALI-2 dimming interface, is ideal for both direct track light projects and new luminaires designed for lighting manufacturers.
| Ambient temperature max.: | 35 °C |
|---|---|
| Ambient temperature min.: | -10 °C |
| DALI Bus Current Consumption: | 0.2150 A |
| Dimming (Output) Interface: | DALI/DALI-2 |
| Driver Type: | Dimming Only |
| Efficiency: | 88.0000 % |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Track Light |
| Operating Mode: | Constant Current |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Output Power: | 26 - 44W |
| Output Voltage: | 6~42V |
| Product height: | 43.4000 mm |
| Product length: | 261.5000 mm |
| Product weight: | 165.0000 g |
| Product width: | 31.0000 mm |
| Push Button Input: | 0 |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Tri-level (Corridor function): | No |
Datasheets
Product datasheet: hed5040.pdf
