HDD2200
DALI Dimmer | Trailing Edge | Wall Junction Box
BENEFITS
- Compact: Designed to fit into Wall Junction Box
- Safe: Over-heat & Over-load Protection
- Streamlined: Convert DALI signals to the trailing edge drivers/transformers
APPLICATIONS
- Built-in box 60mm / Stand alone installation
- Retrofit upgrades & new installations
- Offices, Classrooms, Industry and Healthcare Spaces
Product information "HDD2200"
For use in upgrade retrofit of trailing edge phase dimming controls, this dimmer will convert DALI control signals to the trailing edge drivers or transformers. It can realise savings on installation and wiring costs and will also reduce unnecessary waste of electronic equipment, making it an environmentally sound solution for a lighting control upgrade.
| Ambient temperature max.: | 50 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Application Type: | Dimmers for Wall Junction Box |
| Commissioning Methods: | DALI Master/Application Controller |
| DALI Bus Current Consumption: | 2.0000 mA |
| Dimming (Output) Interface: | DALI/DALI-2 |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product height: | 23.0000 mm |
| Product length: | 48.5000 mm |
| Product weight: | 52.0000 g |
| Product width: | 55.0000 mm |
| Storage temperature max.: | 70 °C |
| Storage temperature min.: | -40 °C |
| Zhaga: | No |
Datasheets
Product datasheet: hdd2200.pdf
