HCD418/I
DALI HF Lowbay | Photocell Advance | Dip-Switch
BENEFITS
- Compact: Super compact size - with photocell advance
- Professional: DALI-2 dimming with PSU
- Simple: Sensor settings via Dip-switch/IR controller
APPLICATIONS
- For round shape luminaire up to 6m height
- Offices
- Classrooms
Product information "HCD418/I"
HCD418D2/I is a low-bay HF sensor with DALI-2 control, featuring built-in tri-level dimming, daylight harvesting, and a human-centric lighting (circadian rhythm) program. It also supports tunable white control.
| Ambient temperature max.: | 60 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | IR Remote Controller |
| Connector Type: | Standard 2 cables |
| Daylight Sensor Option: | Photocell Advance |
| Detection angle: | 30° - 150° |
| Detection range (Diameter): | 12x5 |
| Dimming (Output) Interface: | DALI/DALI-2 |
| Features: | Daylight Harvest, Tri-level (Corridor Function) |
| HF operating frequency (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 0 % |
| IP Rate: | IP20 |
| Installation Type: | Built-in |
| Maximum Mounting Height: | 6.0000 m |
| Mounting Height: | Low-bay |
| Mounting hole: | 4.2000 mm |
| Operating voltage range: | 220-240 VAC 50/60 Hz |
| Product height: | 28.0000 mm |
| Product length: | 102.0000 mm |
| Product weight: | 55.0000 g |
| Product width: | 48.0000 mm |
| Sensitivity: | 10% /50% / 75% / 100% |
| Storage temperature max.: | 80 °C |
| Storage temperature min.: | -35 °C |
| Tri-level (Corridor function): | Yes |
| Voltage Type: | AC |
| Warming-up: | 20 s |
| Zhaga: | No |
Datasheets
Product datasheet: hcd418-i.pdf
Installation Manual
User manual: installation-manual-hcd418-i.pdf
