HC403V-KD
Control body | 1-10V | Dip-Switch
BENEFITS
- Plug&play: Detached Version with 1-10V dimming
- Autonomous: max. loading capacity of 1000VA capacitive
- Simple: Daylight, detection range and holdtime configuration via Dip-Switch
APPLICATIONS
- For round shape luminaire with a height of up to 6m
- Office / Meeting rooms
- Schools / Classroom
Product information "HC403V-KD"
HC403V-KD is a control base featuring plug-and-play connectivity via RJ12 with sensor heads. It supports 1-10V dimming control with relay output and has a maximum loading capacity of 1000VA capacitive. The sensor includes tri-level dimming functionality, and utilizes a Photodiode (PD) for precise light sensing.
| Ambient temperature max.: | 60 °C |
|---|---|
| Ambient temperature min.: | -20 °C |
| Commissioning Methods: | DIP-switch |
| Connector Type: | RJ12 |
| Daylight Harvest: | No |
| Detection Methods: | Microwave (MW) |
| Detection angle: | 30° - 150° |
| Dimming (Output) Interface: | 1-10V |
| HF operating frequency (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | No |
| Humidity max: | 90 % |
| Humidity min: | 10 % |
| IP Rate: | IP20 |
| Installation Type: | Built-in |
| Load capacitive: | 400.0000 VA |
| Load resistive: | 120.0000 W |
| Maximum Mounting Height: | 6.0000 m |
| Mounting Height: | Low-bay |
| Mounting hole: | 4.2000 mm |
| Operating voltage range: | 120-277 VAC |
| Output Voltage: | 120~277VAC |
| Product height: | 27.5000 mm |
| Product length: | 95.0000 mm |
| Product weight: | 70.0000 g |
| Product width: | 48.0000 mm |
| Storage temperature max.: | 50 °C |
| Storage temperature min.: | -20 °C |
| Tri-level (Corridor function): | Yes |
| Voltage Type: | AC |
| Zhaga: | No |
Datasheets
Product datasheet: hc403v-kd.pdf
