HIR19/F
PIR Highbay | Tri-level dimming | RJ12 connector to control body
Vorteile
- Compact: Standard rectangular Plug&Play sensor design
- Simple: Tri-level dimming control with Photocell
- User-Friendly: With one-key commissioning with IR controller
ANWENDUNGEN
- Flush mount installation
- Office/Commercial Lighting
- School/Classrooms
Produktinformationen "HIR19/F"
Designed for flush mount installation, this PIR sensor features tri-level dimming, photocell operation, and active lux switching. It allows easy sensor settings adjustment via handset HRC-11 and offers IP65 protection for durability in various environments.
| Anschlusstyp: | RJ12 |
|---|---|
| Betriebsspannung: | 5 VDC |
| Detektionsverfahren: | Passive Infrared (PIR) |
| Erfassungsbereich (DxH): | 24x15 |
| Features: | Tri-level (Corridor Function) |
| Human Centric Lightning (HCL): | Nein |
| Inbetriebnahmemethoden: | Remote Controller |
| Installationstyp: | Plug & Play Sensor Heads |
| Maximale Montagehöhe: | 15.0000 m |
| Montagehöhe: | High-bay |
| Schutzart: | IP20 |
| Tri-level (Korridorfunktion): | Ja |
| Voltage Type: | DC |
| Warming-up: | 20 s |
