HIR03
PIR Lowbay | Photocell Advance | RJ12-Anschluss an die Steuereinheit
FEATURES
- Kompakt: Rechteckiges Standard-Plug&Play-Sensordesign
- 2-in-1: Tageslichtsteuerung + Photocell Advance
- Praktisch: Einfache Inbetriebnahme per Tastendruck mit IR-Fernbedienung
ANWENDUNGEN
- Master-Leuchte mit Sensor
- Klassenzimmer
- Büros
Produktinformationen "HIR03"
HIR03 ist ein PIR-Sensorkopf mit Unterstützung für die Tageslichtsteuerung. Er ist mit linearen Steuereinheiten wie HCD038V und HCD038/P kompatibel und bietet zahlreiche Plug-&-Play-Optionen für eine flexible Leuchtenkonstruktion.
| Anschlusstyp: | RJ12 |
|---|---|
| Betriebsspannung: | 5 VDC |
| Detektionsbereich (Durchmesser): | 6x3 |
| Detektionsverfahren: | Passiv-Infrarot (PIR) |
| Detektionswinkel: | 360° |
| Eigenschaften: | Tageslichtsteuerung |
| Einbauöffnung: | 13.8000 mm |
| Einschwingzeit: | 20 s |
| Human Centric Lightning (HCL): | Nein |
| IP-Schutzart: | IP20 |
| Inbetriebnahme-Methoden: | IR Fernbedienung |
| Installationstyp: | Plug & Play Sensoren |
| Korridorfunktion: | Nein |
| Lagertemperatur: | 70 °C |
| Max. Luftfeuchtigkeit: | 90 % |
| Maximale Montagehöhe: | 3.0000 m |
| Min. Lagertemperatur: | -40 °C |
| Min. Luftfeuchtigkeit: | 10 % |
| Montagehöhe: | Low-bay |
| Produktbreite: | 17.0000 mm |
| Produktgewicht: | 15.0000 g |
| Produkthöhe: | 19.3000 mm |
| Produktlänge: | 44.5000 mm |
| Spannungsart: | DC |
| Tageslichtsteuerung: | Ja |
| Umgebungstemperatur max.: | 55 °C |
| Umgebungstemperatur min.: | -20 °C |
| Zhaga: | Nein |
Datenblätter
Produktdatenblatt: hir03.pdf
