HED8025/BT
Bluetooth LED Driver 25W | Tunable white | Stand-alone
Vorteile
- Compact: Constant current LED Driver with Bluetooth interface
- Innovative: Featuring Switch-Dim and Bluetooth dimming interfaces
- Easy configuration: via Dip-switch & Wireless Bluetooth 5.0 SIG-Mesh
ANWENDUNGEN
- Retrofit projects with no extra wiring for control
- Offices
- Classrooms
Produktinformationen "HED8025/BT"
Bluetooth Mesh Control With app, 220-240VAC input, Constant current (CC), Multiple current selection via DIP-Switches, Tunable white control, Human Centric Lighting / Circadian Rhythm, Max power: 25W, 2 Switch-Dim (PUSH) terminals.
| Ausgangsleistung: | ≤25W |
|---|---|
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| DALI Gerätetyp: | DT8 |
| Dimmschnittstelle: | Relay On/Off |
| Human Centric Lightning (HCL): | Nein |
| Installationstyp: | Stand-alone |
| Lagertemperatur: | 50 °C |
| Lagertemperatur min.: | -20 °C |
| Operating Mode: | Constant Current |
| Product height: | 30.5000 mm |
| Produktlänge: | 150.0000 mm |
| Produkttiefe: | 53.5000 mm |
| Schutzart: | IP20 |
| Treiber Typ: | Dimming & Color Tuning |
| Tri-level (Korridorfunktion): | Nein |
| Umgebungstemperatur: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Wirkungsgrad: | 88 % |
