HED6045/BT ECO
Bluetooth LED-Treiber 45W (CC) | Dimmbar | Einbau / Standalone
FEATURES
- Kompakt: Linearer LED-Treiber mit Bluetooth-Schnittstelle
- Innovativ: Ausgestattet mit Switch-Dim und Bluetooth-Dimmschnittstelle
- Einfache Konfiguration: über Dip-Schalter & Wireless Bluetooth 5.0 SIG-Mesh
ANWENDUNGEN
- Nachrüstungsprojekte ohne zusätzliche Verkabelung für die Steuerung
- Büros
- Klassenräume
Produktinformationen "HED6045/BT ECO"
Der HED6045/BT ECO ist ein Bluetooth dimmbarer LED-Treiber, mit einer maximalen Ausgangsleistung von 45W. Es kommt mit Switch-Dim-Schnittstelle für die Verwendung von Tastern bzw. Drucktasten (versenkbare Schalter) und natürlich Bluetooth Dimm-Schnittstelle. Er ist ideal für Umrüstprojekte oder Design Projekte neuer Leuchten von Beleuchtungsherstellern. Das Bluetooth Wireless Mesh Networking, macht die Kommunikation zwischen den Leuchten deutlich einfacher, ohne zeitaufwendige zusätzliche Verkabelung, und spart somit Projektkosten.
| Ausgangsleistung: | ≥45W |
|---|---|
| Ausgangsspannung: | 10-54V |
| Betriebsart: | Konstantstrom |
| Betriebsspannung: | 220-240 VAC 50/60 Hz |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Dimm-Steuersignal: | Relais An/Aus |
| Human Centric Lightning (HCL): | Nein |
| IP-Schutzart: | IP20 |
| Inbetriebnahme-Methoden: | App & Web (Bluetooth), DIP-Schalter |
| Installationstyp: | Einbau, Stand-alone |
| Korridorfunktion: | Nein |
| Lagertemperatur: | 50 °C |
| Max. Luftfeuchtigkeit: | 90 % |
| Min. Lagertemperatur: | -20 °C |
| Min. Luftfeuchtigkeit: | 10 % |
| Produktbreite: | 79.2000 mm |
| Produktgewicht: | 171.0000 g |
| Produkthöhe: | 23.0000 mm |
| Produktlänge: | 140.6000 mm |
| Treiber Typ: | Nur Dimmung |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Wirkungsgrad: | 80.0000 % |
Datenblätter
Produktdatenblatt: hed6045-bt-eco.pdf
