HED6010/BT
Bluetooth LED-Treiber 12.5W | Dimmbar | Stand-alone Version
FEATURES
- Kompakt: Linearer LED-Treiber mit Bluetooth-Schnittstelle
- Effizient: Loop-in & Loop-out Terminals Design
- Einfache Konfiguration: über Dip-Schalter & Wireless Bluetooth 5.0 SIG-Mesh
ANWENDUNGEN
- Freistehende Installation
- Ämter
- Klassenzimmer
Produktinformationen "HED6010/BT"
Bluetooth Mesh Control mit App, 220-240VAC Eingang, Konstantstrom (CC), Mehrfachstromauswahl über DIP-Schalter, Max. Leistung: 12,5W, 2 Switch-Dim (PUSH) Anschlüsse.
Ausgangsleistung: | ≤25W |
---|---|
Betriebsart: | Konstantstrom |
Betriebsspannung: | 220-240 VAC 50/60 Hz |
Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
Bluetooth Reichweite: | 10-30m |
Bluetooth Sendeleistung: | 4 dBm |
Bluetooth System: | Koolmesh |
DALI Gerätetyp: | DT6 |
Dimm-Schnittstelle: | Relais An/Aus |
Einbauöffnung: | 4.1000 mm |
Human Centric Lightning (HCL): | Nein |
IP-Schutzart: | IP20 |
Installationstyp: | Stand-alone |
Korridorfunktion: | Nein |
Lagertemperatur: | 50 °C |
Min. Lagertemperatur: | -20 °C |
Produktbreite: | 52.0000 mm |
Produktgewicht: | 115.0000 g |
Produkthöhe: | 28.0000 mm |
Produktlänge: | 150.0000 mm |
Treiber Typ: | Nur Dimmung |
Umgebungstemperatur max.: | 50 °C |
Umgebungstemperatur min.: | -20 °C |
Wirkungsgrad: | 82 % |
Datenblätter
Produktdatenblatt: hed6010-bt.pdf
