HBTD15/S
Bluetooth Dimmer | DALI Broadcast | Zhaga Book 18 Standard
FEATURES
- Compact: Complying with Zhaga Book 18 for easy luminaire integration
- Reliable：Ensuring stable wireless dimming and tunable white
- Efficient: Enabling quick setup via Koolmesh app
ANWENDUNGEN
- DALI Application
- Outdoor/Street lights
- Warehouse/ Logistic
Produktinformationen "HBTD15/S"
HBTD15S is a Zhaga Book 18 compliant Bluetooth DALI broadcast dimming controller designed for smart luminaires. It enables seamless wireless communication between drivers and luminaires, allowing precise dimming and color tuning without additional wiring, which simplifies installation and enhances the value of each fixture. The controller features an onboard FPC antenna for stable connectivity and supports pairing with standard DALI-2 or D4i drivers. All configuration and commissioning can be quickly completed via the Koolmesh app. With compact design, low power consumption, and robust performance.
| Anwendungsstyp: | Zhaga Book 18 Standard |
|---|---|
| Betriebsspannung: | 12-36 VDC |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Dimm-Steuersignal: | DALI/DALI-2 |
| Human Centric Lightning (HCL): | Nein |
| IP-Schutzart: | IP65 |
| Inbetriebnahme-Methoden: | App & Web (Bluetooth), DALI Master/Application Controller |
| Korridorfunktion: | Nein |
| Lagertemperatur: | 55 °C |
| Max. Luftfeuchtigkeit: | 90 % |
| Min. Lagertemperatur: | -35 °C |
| Min. Luftfeuchtigkeit: | 20 % |
| Produktbreite: | 50.8000 mm |
| Produktgewicht: | 50.8000 g |
| Produkthöhe: | 35.0000 mm |
| Produktlänge: | 31.0000 mm |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Zhaga: | Ja |
Datenblätter
Produktdatenblatt: hbtd15-s.pdf
