HBIR28/2CH/R
PIR Lowbay | Bluetooth and ON/OFF | 2 channels
Vorteile
- Adaptable: Lens and blind variants for different detection ranges
- Versatile: Motion and daylight control via Bluetooth
- 2 Channels: additional on/off Relay 400VA and voltage-free contact
ANWENDUNGEN
- Standalone installation for ceiling up to 6m
- Office / Meeting rooms
- Schools / Classroom
Produktinformationen "HBIR28/2CH/R"
It is a Bluetooth PIR standalone motion sensor with On/Off control and two independent relay channel outputs. It features a dual-function relay (NO/NC) and a normally closed relay. Ideal for offices, classrooms, healthcare, and commercial areas, it enables easy luminaire communication via Bluetooth mesh networking.
Anschlusstyp: | Standard 2 cables |
---|---|
Ausgangsschnittstelle: | Relais On/Off |
Befestigungsloch: | 66.0000 mm |
Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
Bluetooth Reichweite: | 10-30m |
Bluetooth Sendeleistung: | 4 dBm |
Bluetooth System: | Koolmesh |
Bluetooth Technologie: | Nordic nRF52832 |
Daylight Harvest: | Nein |
Detection angle: | 360° |
Detektionsverfahren: | Passive Infrared (PIR) |
Erfassungsbereich (DxH): | 10x6 |
Feuchtigkeit max: | 90 % |
Feuchtigkeit min: | 10 % |
Human Centric Lightning (HCL): | Nein |
Inbetriebnahmemethoden: | App & Web (Bluetooth) |
Installationstyp: | Stand-alone |
Lagertemperatur: | 70 °C |
Lagertemperatur min.: | -40 °C |
Lens type: | Reinforced Low-bay |
Maximale Montagehöhe: | 6.0000 m |
Montagehöhe: | Low-bay |
Product height: | 77.6000 mm |
Produkttiefe: | 78.0000 mm |
Schutzart: | IP20 |
Tageslicht Sensor Option: | Ordinary Photodiode/Photocell |
Taster Eingänge: | 4 |
Tri-level (Korridorfunktion): | Nein |
Umgebungstemperatur: | 50 °C |
Umgebungstemperatur min.: | -20 °C |
Voltage Type: | AC |
Warming-up: | 20 s |
Zhaga: | No |
