HMW27/AA
HF Lowbay | Tri-level/DALI with PSU | Adjustable Angle
Vorteile
- Adjustable: Max.,70 degree angle + 360 degree rotatable for detection
- 2 in 1: 80mA DALI power supply built-in + Tri-level control
- User-Friendly: With one-key commissioning via IR controller
ANWENDUNGEN
- For wall/surface mount application
- Corridor, Hallway
- Classrooms, Offices
Produktinformationen "HMW27/AA"
It is a HF standalone motion sensor, with one DALI channel output (80mA DALI power supply built-in). Designed in a metal surface mount box, it features adjustable detection angles, capable of 360-degree rotation and extending up to 70 degrees for maximum angle adjustment
| Anschlusstyp: | Standard 2 cables |
|---|---|
| Ausgangsschnittstelle: | DALI & DALI-2 |
| Befestigungsloch: | 4.2000 mm |
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Daylight Harvest: | Ja |
| Detection angle: | 360° |
| Detektionsverfahren: | Microwave (MW) |
| Erfassungsbereich (DxH): | 2.5×22 |
| Erforderlicher DALI-Strom: | 90.0000 mA |
| Features: | Adjustable Angle, Tri-level (Corridor Function) |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| Human Centric Lightning (HCL): | Nein |
| Inbetriebnahmemethoden: | Remote Controller |
| Installationstyp: | Stand-alone |
| Lagertemperatur: | 70 °C |
| Lagertemperatur min.: | -40 °C |
| Maximale Montagehöhe: | 3.0000 m |
| Montagehöhe: | High-bay |
| Product height: | 115.0000 mm |
| Produktlänge: | 94.0000 mm |
| Produkttiefe: | 94.0000 mm |
| Schutzart: | IP20 |
| Tageslicht Sensor Option: | Ordinary Photodiode/Photocell |
| Taster Eingänge: | 1 |
| Tri-level (Korridorfunktion): | Ja |
| Umgebungstemperatur: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Voltage Type: | AC |
| Zhaga: | No |
