HIM98-C-L3
HF+PIR Highbay | Bluetooth 1-10V oder ON/OFF | Aufbaumontage
FEATURES
- Hohe Genauigkeit: DUAL Sense mit HF- und PIR-Technologie
- Einfach: Dreistufige Steuerung & Tageslichtnutzung
- Einfache Konfiguration: Drahtloses Bluetooth 5.0 SIG-Mesh
ANWENDUNGEN
- Freistehende Installation für Decken bis zu 15m
- Lagerhaus
- Produktion
Produktinformationen "HIM98-C-L3"
HIM98 ist ein Bluetooth 1-10V High-Bay Dual-Sense (Mikrowelle + PIR) Bewegungssensor, mit der Fähigkeit, bis zu 15m Installationshöhe. Er ist mit einer robusten IP65-Struktur ausgestattet und bietet 3 verschiedene Installationsmethoden und 3 verschiedene Linsenoptionen.
| Anschlusstyp: | 2-adrig |
|---|---|
| Betriebsspannung: | 220-240 VAC 50/60 Hz |
| Bluetooth-Plattform: | Nordic nRF52832 |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Detektionsbereich (Durchmesser): | 24x15 |
| Detektionsverfahren: | Dual-Sense (MW+PIR), Mikrowellensensor (MW), Passiv-Infrarot (PIR) |
| Detektionswinkel: | 360° |
| Dimm-Steuersignal: | 0/1-10V |
| Eigenschaften: | Korridorfunktion, Tageslichtsteuerung |
| Einbauöffnung: | 4.1000 mm |
| Einschwingzeit: | 20 s |
| Erforderlicher DALI-Strom: | 20.0000 mA |
| HF Betriebsfrequenz (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | Ja |
| IP-Schutzart: | IP65 |
| Inbetriebnahme-Methoden: | App & Web (Bluetooth) |
| Installationstyp: | Klemmenmontage |
| Korridorfunktion: | Ja |
| Lagertemperatur: | 70 °C |
| Linsentyp: | High-bay |
| Max. Luftfeuchtigkeit: | 90 % |
| Maximale Montagehöhe: | 15.0000 m |
| Min. Lagertemperatur: | -40 °C |
| Min. Luftfeuchtigkeit: | 10 % |
| Montagehöhe: | Mid & High-bay |
| Produktbreite: | 81.5000 mm |
| Produktgewicht: | 220.0000 g |
| Produkthöhe: | 93.8000 mm |
| Produktlänge: | 91.5000 mm |
| Scheinleistung: | 800.0000 VA |
| Spannungsart: | AC |
| Tageslichtsteuerung: | Ja |
| Taster Eingänge: | 0 |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Wirkleistung: | 1000.0000 W |
| Zhaga: | Nein |
Datenblätter
Produktdatenblatt: him98-c-l3.pdf
