HIM450VDS/BT
HF+PIR Highbay | Bluetooth DALI | Wall/Surface mounting
FEATURES
- High accuracy: DUAL Sense with HF and PIR technology
- Versatile: DALI + 0/1-10V Dimming + Tri-level + Daylight harvest + Circadian Rhythm
- Easy configuration: Wireless Bluetooth 5.0 SIG-Mesh
ANWENDUNGEN
- Standalone installation for ceiling up to 20m
- Warehouse, Large storage room
- Production
Produktinformationen "HIM450VDS/BT"
HIM450VDS/BT is a Bluetooth high-bay Dual-sense™ (Microwave + PIR) motion sensor with an installation height of up to 20 m. It supports DALI/DALI-2 output, 0/1-10V dimming, and relay output, as well as 2-channel on/off control (Switched L + VFC). With a built-in daylight sensor, it enables tri-level dimming, daylight harvesting, and Human Centric Lighting/Circadian Rhythm applications. Designed for large spaces such as warehouses and storage facilities, it allows fast and simple setup via the Koolmesh app.
| Anschlusstyp: | 2-adrig |
|---|---|
| Ausgangsspannung: | 220-240VAC 50/60Hz |
| Bluetooth-Plattform: | Nordic nRF52832 |
| Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Detektionsverfahren: | Dual-Sense (MW+PIR) |
| Dimm-Steuersignal: | 0/1-10V, Relais An/Aus, Volt-free Contact (VFC) |
| Eigenschaften: | Einstellbare Weißlichtsteuerung, Korridorfunktion, Tageslichtsteuerung |
| Einschwingzeit: | 20 s |
| Empfindlichkeit: | 10%/ 30% /50% /75%/ 100% |
| Erfassungsbereich (Durchmesser): | 25×15 |
| HF Betriebsfrequenz (Ghz): | 10.525GHz +/- 75MHz |
| Human Centric Lightning (HCL): | Ja |
| IP-Schutzart: | IP65 |
| Inbetriebnahme-Methoden: | App & Web (Bluetooth), DALI Master/Application Controller |
| Installationstyp: | Stand-alone |
| Korridorfunktion: | Ja |
| Lagertemperatur: | 70 °C |
| Linsentyp: | Ultra high-bay |
| Max. Luftfeuchtigkeit: | 60 % |
| Maximale Montagehöhe: | 25.0000 m |
| Min. Lagertemperatur: | -40 °C |
| Min. Luftfeuchtigkeit: | 10 % |
| Montagehöhe: | Ultra High-bay |
| Produktbreite: | 97.0000 mm |
| Produktgewicht: | 450.0000 g |
| Produkthöhe: | 82.7000 mm |
| Produktlänge: | 135.0000 mm |
| Spannungsart: | AC |
| Stromverbrauch: | 2.0000 mA |
| Tageslichtsensor-Option: | Photodiode/Fotowiderstand |
| Tageslichtsteuerung: | Ja |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Zhaga: | Nein |
Datenblätter
Produktdatenblatt: him450vds-bt.pdf
