HED7030/BT ECO
Bluetooth LED Driver 30W (CC) | Dimmable | Built-in version
FEATURES
- Compact: 30W LED Driver with Bluetooth interface
- Innovative: Featuring Switch-Dim and Bluetooth dimming interfaces
- Easy: Motion and Daylight harvest configuration via Koolmesh app
ANWENDUNGEN
- Luminaires with integrated sensor
- Retrofit projects with no extra wiring for control
- All types of indoor applications
Produktinformationen "HED7030/BT ECO"
HED7030/BT ECO is a Bluetooth dimmable LED driver, with maximum power output of 30W. It come with Switch-Dim interface by using Push switch (retractive switch) and of course Bluetooth dimming interface. It is ideal for direct projects or new luminaires design for lighting manufacturers. With Bluetooth wireless mesh networking, it makes communication between luminaires much easier without time-consuming hardwiring, which eventually saves costs for projects.
| Ausgangsleistung: | 26 - 44W |
|---|---|
| Ausgangsspannung: | 10-57V |
| Betriebsart: | Konstantstrom |
| Betriebsspannung: | 220-240 VAC 50/60 Hz |
| Bluetooth Frequenz: | 2.4 GHz |
| Bluetooth Reichweite: | 10-30m |
| Bluetooth Sendeleistung: | 4 dBm |
| Bluetooth System: | Koolmesh |
| Dimm-Schnittstelle: | DALI2 |
| Einbauöffnung: | 4.1000 mm |
| Human Centric Lightning (HCL): | Nein |
| Inbetriebnahme-Methoden: | App & Web (Bluetooth), DIP-Schalter |
| Installationstyp: | Built-in |
| Korridorfunktion: | Nein |
| Lagertemperatur: | 70 °C |
| Max. Luftfeuchtigkeit: | 90 % |
| Min. Lagertemperatur: | -40 °C |
| Min. Luftfeuchtigkeit: | 10 % |
| Produktbreite: | 69.0000 mm |
| Produktgewicht: | 138.0000 g |
| Produkthöhe: | 22.2000 mm |
| Produktlänge: | 108.0000 mm |
| Schutzart: | IP20 |
| Taster Eingänge: | 2 |
| Treiber Typ: | Nur Dimmung |
| Umgebungstemperatur max.: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Wirkungsgrad: | 86 % |
