HBIR31/R
PIR Lowbay | Bluetooth DALI with PSU | Ceiling mounting
Vorteile
- Efficient: Standalone sensor for easy refurbishment
- Simple: Tri-level control & Daylight harvest
- Easy configuration: Wireless Bluetooth 5.0 SIG-Mesh
ANWENDUNGEN
- Standalone installation for ceiling up to 6m
- Office / Meeting rooms
- Schools / Classroom
Produktinformationen "HBIR31/R"
HBIR31/R is a Bluetooth PIR standalone motion sensor with 80mA DALI
power supply built in, which can control up to 40 LED drivers. It is
ideal for typical indoor applications such as ofce, classroom,
healthcare and other commercial areas. With Bluetooth wireless mesh
networking, it makes communication between luminaires much easier
without time-consuming hardwiring.
Anschlusstyp: | Standard 2 cables |
---|---|
Ausgangsschnittstelle: | DALI |
Befestigungsloch: | 66.0000 mm |
Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
Bluetooth Frequenz: | 2.4 GHz - 2.483 GHz |
Bluetooth Reichweite: | 10-30m |
Bluetooth Sendeleistung: | 4 dBm |
Bluetooth System: | Koolmesh |
Bluetooth Technologie: | Nordic nRF52832 |
Daylight Harvest: | Ja |
Detection angle: | 360° |
Detektionsverfahren: | Passive Infrared (PIR) |
Erfassungsbereich (DxH): | 10x6 |
Erforderlicher DALI-Strom: | 80.0000 mA |
Features: | D4i, Daylight Harvest, Tri-level (Corridor Function) |
Feuchtigkeit max: | 90 % |
Feuchtigkeit min: | 10 % |
Human Centric Lightning (HCL): | Nein |
Inbetriebnahmemethoden: | App & Web (Bluetooth) |
Installationstyp: | Stand-alone |
Lagertemperatur: | 70 °C |
Lagertemperatur min.: | -40 °C |
Lens type: | Standard Low-bay |
Maximale Montagehöhe: | 6.0000 m |
Montagehöhe: | Low-bay |
Product height: | 77.6000 mm |
Produkttiefe: | 78.0000 mm |
Schutzart: | IP20 |
Tageslicht Sensor Option: | Ordinary Photodiode/Photocell |
Taster Eingänge: | 2 |
Tri-level (Korridorfunktion): | Ja |
Umgebungstemperatur: | 50 °C |
Umgebungstemperatur min.: | -20 °C |
Voltage Type: | AC |
Warming-up: | 20 s |
Zhaga: | No |
