SAM13/RC12/H
HF Highdbay | ON/OFF | RJ12 connector to control body
Vorteile
- Compact: Standard rectangular Plug&Play sensor design
- Innovative: Robust HF antenna design against wireless interference
- User-Friendly: With one-key commissioning with IR controller
ANWENDUNGEN
- Master luminaire with sensor
- Classrooms
- Offices
Produktinformationen "SAM13/RC12/H"
SAM13/RC12/H is a HF sensor head and compatible with the On/Off Control. It can work with the linear shaped control base such as HCD038V and HCD038/P. It offers powerful number of Plug’n’Play feature options to expand the flexibility of luminaires design.
| Ausgangsschnittstelle: | Relais On/Off |
|---|---|
| Betriebsspannung: | 5 VDC |
| Daylight Harvest: | Nein |
| Detection angle: | 30° - 150° |
| Detektionsverfahren: | Microwave (MW) |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| HF Betriebsfrequenz (Ghz): | 5.8Ghz+/-75MHz |
| Human Centric Lightning (HCL): | Nein |
| Installationstyp: | Plug & Play Sensor Heads |
| Lagertemperatur: | 70 °C |
| Lagertemperatur min.: | -40 °C |
| Lens type: | High-bay |
| Montagehöhe: | High-bay |
| Product height: | 16.0000 mm |
| Produktlänge: | 52.5000 mm |
| Produkttiefe: | 31.2000 mm |
| Schutzart: | IP20 |
| Tri-level (Korridorfunktion): | Nein |
| Umgebungstemperatur: | 55 °C |
| Umgebungstemperatur min.: | -20 °C |
| Voltage Type: | DC |
| Zhaga: | No |
