HIM14
PIR + HF Lowbay | Daylight Harvest & DALI | Remote Controller
Vorteile
- Flexible: Surface/Flush mounting or inside junction box
- All in one: Daylight harvest + Synchronisation Function + Manual Override
- User-Friendly: With one-key commissioning with Remote Control
ANWENDUNGEN
- Standalone installation for ceiling up to 12m
- Warehouse
- Logistic
Produktinformationen "HIM14"
HIM14 is a standalone dual sense motion sensor equipped with both HF and PIR technologies. It offers daylight harvest control for independent DALI, and comes with a remote control for easy adjustments, making it ideal for efficient lighting management.
Anschlusstyp: | Standard 2 cables |
---|---|
Ausgangsschnittstelle: | DALI |
Ausgangsspannung: | 120-277VAC |
Befestigungsloch: | 38.6000 mm |
Betriebsspannung: | 120 - 277 VAC |
Daylight Harvest: | Ja |
Detection angle: | 360° |
Detektionsverfahren: | Dual-Sense (MW+PIR) |
Erfassungsbereich (DxH): | 12x6 |
Erforderlicher DALI-Strom: | 40.0000 mA |
Features: | Daylight Harvest |
Feuchtigkeit max: | 90 % |
Feuchtigkeit min: | 10 % |
HF Betriebsfrequenz (Ghz): | 5.8Ghz+/-75MHz |
Human Centric Lightning (HCL): | Nein |
Inbetriebnahmemethoden: | Remote Controller |
Installationstyp: | Stand-alone |
Maximale Montagehöhe: | 6.0000 m |
Montagehöhe: | Low-bay |
Product height: | 55.2000 mm |
Produkttiefe: | 109.0000 mm |
Schutzart: | IP20 |
Tageslicht Sensor Option: | Ordinary Photodiode/Photocell |
Taster Eingänge: | 1 |
Tri-level (Korridorfunktion): | Nein |
Umgebungstemperatur: | 55 °C |
Umgebungstemperatur min.: | -20 °C |
Voltage Type: | AC |
Zhaga: | No |
