HED8025
DALI-2 DT8 LED Driver 25W | Turnable white | Built-in/Stand-alone
Vorteile
- Compact: LED Driver with DALI feedback
- Flexible: Switch-Dim(PUSH) terminal
- Easy: Configurable constant current (CC) output via DIP switches
ANWENDUNGEN
- Optional terminal-cap for stand-alone installation
- Offices
- Classrooms
Produktinformationen "HED8025"
The HED8025/BT is a Bluetooth dimming and tunable white LED driver with a maximum power output of 25W to 40W. It features a Switch-Dim interface using a push switch and a Bluetooth dimming interface. Ideal for new luminaire designs, it supports Bluetooth wireless mesh networking, simplifying communication and reducing installation costs. Device setup and commissioning are easily done via the Koolmesh app.
| Ausgangsspannung: | 220-240VAC 50/60Hz |
|---|---|
| Befestigungsloch: | 4.1000 mm |
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| Installationstyp: | Built-in, Stand-alone |
| Lagertemperatur: | 70 °C |
| Lagertemperatur min.: | -40 °C |
| Operating Mode: | Constant Voltage |
| Product height: | 30.5000 mm |
| Produktlänge: | 150.0000 mm |
| Produkttiefe: | 53.5000 mm |
| Schutzart: | IP20 |
| Treiber Typ: | Dimming & Color Tuning |
| Umgebungstemperatur: | 50 °C |
| Umgebungstemperatur min.: | -20 °C |
| Wirkungsgrad: | 80 % |
