HED5040
DT8 LED Driver 40W Tunable White | 6 Wires 3 Circuits | Track System Stucci
Vorteile
- Standardized: 3-phase dial for phase selection
- Professional: With DALI-2 dimming interface
- Easy: Configurable constant current (CC) output via DIP switches
ANWENDUNGEN
- Designed to fit into stucci track system
- Offices, Retail stores, Warehouse
- Museums, Galleries
Produktinformationen "HED5040"
HED5040 is a DALI-2 dimmable LED driver for the track system, with 3-phase dial and maximum power output of 40W. The installation only requires simple insertion into the track. HED5040 has a DALI-2 dimming interface, is ideal for both direct track light projects and new luminaires designed for lighting manufacturers.
| Ausgangsspannung: | 6~42V |
|---|---|
| Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
| Dimmschnittstelle: | DALI2 |
| Erforderlicher DALI-Strom: | 0.2150 A |
| Feuchtigkeit max: | 90 % |
| Feuchtigkeit min: | 10 % |
| Human Centric Lightning (HCL): | Nein |
| Installationstyp: | Stromschienen Beleuchtung |
| Lagertemperatur: | 70 °C |
| Lagertemperatur min.: | -40 °C |
| Product height: | 43.4000 mm |
| Produktlänge: | 261.5000 mm |
| Produkttiefe: | 31.0000 mm |
| Schutzart: | IP20 |
| Taster Eingänge: | |
| Treiber Typ: | Dimming & Color Tuning |
| Tri-level (Korridorfunktion): | Nein |
| Umgebungstemperatur: | 35 °C |
| Umgebungstemperatur min.: | -10 °C |
| Wirkungsgrad: | 88 % |
