HDS2400
DALI Switch | ON/OFF | Wall Junction Box
Vorteile
- Compact: Designed to fit into Wall Junction Box
- Autonomous: On/off occupancy control for up to 800W
- Easy: DALI addressable
ANWENDUNGEN
- Retrofit for non-dimmable LED drivers, transformer or uorescent ballasts
- Built-in box 60mm / Stand alone installation
- Offices, Classrooms, Industry and Healthcare Spaces
Produktinformationen "HDS2400"
This on/off DALI controlled switch is ideally suited for retrofit where non-dimmable
LED drivers, transformer or fluorescent ballasts have been used. Saving costs on
installation, components and wiring, this convertor is an extremely cost effective
and environmentally sound solution for a lighting control upgrade.
Application Type: | Dimmers for Wall Junction Box |
---|---|
Ausgangsschnittstelle: | DALI |
Betriebsspannung: | 220 - 240 VAC 50/60 Hz |
Erforderlicher DALI-Strom: | 2.0000 mA |
Feuchtigkeit max: | 90 % |
Feuchtigkeit min: | 10 % |
Inbetriebnahmemethoden: | DALI Master/Application Controller |
Lagertemperatur: | 70 °C |
Lagertemperatur min.: | -40 °C |
Product height: | 23.0000 mm |
Produktlänge: | 51.0000 mm |
Produkttiefe: | 48.5000 mm |
Schutzart: | IP20 |
Umgebungstemperatur: | 50 °C |
Umgebungstemperatur min.: | -20 °C |
Zhaga: | No |
